16
TORQUE CHART FOR YUVRAJ 215 - FMW100 ENGINE
SR. DESCRIPTION & BOLT/NUT/STUD USED TORQUE-Nm
NO.
INJECTION EQUIPMENT SUB- ASSEMBLY
37 Hex Nut for FIP (M8 - 8) 18 to 22 Nm
38 Hex bolt for H.P.pipe clamp mtg (M8x16-8.8) 25 to 30 Nm
39 Injector flange Hex Nut (M8 - 8) 25 to 30 Nm
40 Fuel filter bkt Mrg bolt (M10 x 30 - 8.8) 45 to 50Nm
41 Hex Nut for fuel filter mtg bolt (M10 - 8) 45 to 50 Nm
42 Fuel filter mtg bolt (M10 x 30 - 8.8) 45 to 50 Nm
43 Banjo Bolt M14 for fuel filter 20 to 25 Nm
44 M6 Banjo bolt for injector overflow pipe 5 to 7 Nm
AIR FILTER, EXHAUST SILENCER SUB-ASSEMBLY
45 Exh. Manifold manifold hex nut (M10) 45 to 50 Nm
46 Hex bolt for stub pipe mtg (M8 x 30-8.8) 25 to 30 Nm
47 Hex nut for stub mtg bolt (M8 – 8.8) 25 to 30 Nm
48 Hex nut for silencer clamp (M8 – 8.8) 25 to 30 Nm
49 Air cleaner manifold hex nut (M10 – 8.8) 45 to 50 Nm
STARTER MOTOR, ALTERNATOR SUB-ASSEMBLY
50 Hex bolt for starter mtg (M10 x 30 - 8.8) 45 to 50 Nm
51 Hex bolt for Alternator mtg bkt (M8 x 20 - 8.8) 25 to 30 Nm
52 Hex bolt for Alternator mtg (M8 x 110 - 8.8) 25 to 30 Nm
53 Hex bolt for Radial bkt (M 8 x 25 - 8.8) 25 to 30 Nm
54 Nut for Alternator Adj bolt (M8) 25 to 30 Nm
To Next Page
