Frame drop device PFL-P
Consisting of:
compressed air cylinder, regulating valve,
solenoid valve and Bowden cable.
Order reference: PFL-P
The frame drop devices PFL-M and PFL-P can be obtained directly from us.
The stop motors and frame drop devices must be switched to give the following
sequence:
Positioning (needle in extreme left position)
Cutting with treadle position fully down
Dropping / opening of the table (frame)
Intermediate dropping without cutting is possible at the treadle mid-position.
Attention - operators please note:
The table (frame) is under strong spring tension. So always make sure that your
fingers are outside the danger zone when you release the treadle after the cutting and
dropping process.
Accessories:
Thread stand, treadle with transmission linkage or knee-lift lever, chains, hooks, 2-part
belt guard plate, finger guard (not with classes 220, 221, 271), oiler, screwdriver,
open-ended spanner, Allen key, cover, spare parts list.
