Technical data
Class
220, 221, 240,
241, 251, 271
Class
252
Class
352
Class
261
Class
221-19/2, 221-
19/4
Number of stitches/min up to
3000
2500
2500
2300
2000
Length of stitch
3-8 mm
3-8 mm
3-8 mm
3-8 mm
2-8 mm
Hand-wheel diameter
(effective)
63 mm
63 mm
63 mm
63 mm
63 mm
V-belt width
10 mm
10 mm
10 mm
10 mm
10 mm
Motor power
0.25 kW
0.25 kW
0.25 kW
0.25 kW
0.25 kW
Motor speed
1400 rpm
1400 rpm
1400 rpm
1400 rpm
1400 rpm
Motor shaft V-belt pulley
(effective diameter)
125 mm
106 mm
106 mm
100 mm
90 mm
Needle system
System 251 EU
System 251 LG
System 251 EU
System 251 LG
System 251
Noise
75 dbA
75 dbA
75 dbA
75 dbA
75 dbA
If a very accurate stitch penetration is required, it is advisable to run the machine at
reduced speed and to select a V-belt pulley approx. 20% smaller.
approx. 2500 rpm with a 106 mm diameter motor shaft V-belt pulley
approx. 2300 rpm with a 100 mm diameter motor shaft V-belt pulley
approx. 1800 rpm with an 86 mm diameter motor shaft V-belt pulley.
