Spin the machine by hand. Here, the needle should slide on the needle plate A with no
clearance until stitching the cloth, but it must not be lifted by it either. When the needle
is at the farthest right position B, the play between needle and stitch plate should be
approx. 1/10 mm. In addition, the feed dog must be located in the centre of the stitch
plate cut-out.
Slacken the two stitch plate fixing screws and the hexagon bolt on the rear stitch
plate mounting.
Retighten them slightly.
Now you can move the stitch plate to the required position.
Tighten screws and bolt.
A setting gauge is available for basic setting of the stitch plate (Order. No. V241101).
