GB-20
Cancelling the Alarm
1.
Press ALARM button on the remote control, the display shows “Alarm (1 or 2): On [hh:mm]”.
2.
Press the ▶" ^/▼ □ buttons to select the Alarm number (1 or 2) and then press SELECT button to start
the setting of the timer.
3.
Press the ▶" ^/▼ □ buttons to select “Enable” then press the SELECT button to confirm.
4.
Press the ▶" ^/▼ □ buttons to select “Off” then press the SELECT button to confirm.
5.
Finally, select "Save" and press the SELECT button to save the setting.
6.
Alternatively, during Standby mode, press the ALARM button on remote control repeatedly can turn
the saved Alarm 1/2 on/off sequentially.
Specification
Brand
Majority
Model
Fitzwilliam 3
System
Section
Power
Supply
AC100-240V ~ 50/60Hz
Power Consumption
7.8W
Working Environment -
Temperature
0 ~ 35 °C
Net
Weight
Main unit: app. 2.3 kg
Unit Dimension (W) × (D) × (H)
435 x 298 x 74 mm
Radio
Frequency
FM 87.50 – 108.00 MHz
DAB 174.928 - 239.200 MHz
How to activate wireless network port:
● Connect the unit with power
● Switch to wireless mode (e.g. Internet)
How to deactivate wireless network port:
● Go to Main menu - System Settings - Network - Keep Network Connected. Select No and then
press SELECT button to keep network disconnected
Bluetooth
version
Version
V4.2(only support BR+EDR)
Maximum Transmitted Power
5 dBm
Frequency
Band
2402 - 2480 MHz
Wifi
Maximum Transmitted Power
15 dBm
Frequency
Band
2412 - 2472 MHz
Standby Power Consumption:
WiFi Off: < 1.00 W (Standard Standby Mode)
WiFi On: < 2.00 W (Network Standby Mode)
