MAKERBOT REPLICATOR 2X DIAGRAMS
[1] GANTRY SYSTEM
[2] LCD PANEL
[3] HEATED BUILD PLATE
[4] BUILD PLATFORM
[5] THREADED Z-AXIS ROD
[6] ENCLOSURE DOOR HANDLE
[7] FILAMENT GUIDE TUBES
[8] EXTRUDER CABLE
[9] EXTRUDERS
[10] FILAMENT SPOOL
[11] SPOOL HOLDERS
