WELCOME.11
ABOUT THE MAKERBOT REPLICATOR Z18
1
MAKERBOT REPLICATOR DIAGRAMS
4. Control panel
5. Filament drawer
1. Build plate
2. Filament waste bin
3. Build plate latches
5
2
4
3
6. Smart Extruder
6
