STARTUP26
THE MAKERBOT REPLICATOR Z18 CONTROL PANEL
The MakerBot Replicator Z18 is operated by means of a control panel at the lower right of the
3D printer. The control panel includes a color LCD screen, a rotary/push dial, and two buttons.
See chapter 5 for more on the control panel and its menus.
• • Turn the dial to scroll through the available options on a screen.
• • Press the dial to make a selection.
• • Press the back button to return to the previous section or cancel an action.
• • Press the menu button to open a menu with additional options. If a menu is
available, a menu icon will appear at the lower right corner of the screen.
•
4 521 3
4. Dial
5. USB drive port
1. LCD screen
2. Menu button
3. Back button
