Special tools
164
33
1
2
3
4
5
6
34
35
Fig. no. Designation Item code
33 Measuring combination, consisting of:
(1) Dial gauge 08.71000-1205
(2) Tracing pin for dial gauge 80.99605-0197
(3) Dial gauge bracket 80.99605-0179
(4) Seating pin 80.99605-0180
(5) Dial gauge bracket 80.99605-6006
(6) Dial gauge bracket 80.99605-0172
34 Press-on measuring plate 80.99605-0195
35 Adjusting sleeves 51.91701-0247
