20
21
Repairing coolant pump with high-temperature and
low-temperature parts D 2866 LUE 605
53
Fig. 20
Fit new pump cover and press it into housing,
using a suitable pressing tool.
Fig. 21
If no suitable pressing tool is available, you may
use self-made special tools (see chapter “Special
tools”) and proceed as follows:
D Align guide ring Á with the two dowel pins on
the pump housing
D Insert pressing ring À into guide ring
D Place a flat steel (min. thickness: 10 mm) on
the pressing ring
D Press cover into housing using a press
Attach water pump with new seal, see page, 41.
1
2
