Page 81Version 2023-06-15 Fire damper - FDMR
TPM 140/19
Installation frame R6
■ Installation frames R6 is designed for installation without additional sealing of the penetration for:
■ Installation outside solid wall/ceiling construction with insulation from fire-resistant boards
Installation frame is equipped with an intumescent sealing on the inside. This sealing fills the gap between the damper
casing and frame in the event of a fire
■ Material:
■ Installation frame - cement-lime boards
■ Fasteners - galvanized steel
100
160
50
ØD+170
ØD+90
Installation frame R6
