Mandik FDMR - Statement of Installations

Page 27Version 2023-06-15 Fire damper - FDMR
TPM 140/19
Statement of installations
Installation
wall/ceiling
min. thickness
[mm]
Method of installation Fire resistance Page
In solid wall construction 100
Mortar or gypsum
EI 90 (v
e
i↔o) S
EI 120 (v
e
i↔o) S
28
2 dampers in one opening - mortar or gypsum
EI 90 (v
e
i↔o) S
29
Weichschott system 30
Mineral wool with fire-resistant coating and fire-resistant boards 31
Fire-resistant foam with stucco plaster
EI 60 (v
e
i↔o) S
32
Installation next to the wall/ceiling - mortar or gypsum + mineral wool
EI 90 (v
e
i↔o) S
33
Installation next to the wall/ceiling - mortar or gypsum 34
Outside solid wall construction 100
ISOVER Ultimate Protect - mortar or gypsum
EI 60 (v
e
i↔o) S
EI 90 (v
e
i↔o) S
35
ISOVER Ultimate Protect - Weichschott system 36
Mineral wool ROCKWOOL - Mineral wool with fire-resistant coating and fire-
resistant board
EI 90 (v
e
i↔o) S
37
In gypsum wall construction 100
Mortar or gypsum
EI 90 (v
e
i↔o) S
EI 120 (v
e
i↔o) S
38
2 dampers in one opening - mortar or gypsum
EI 90 (v
e
i↔o) S
39
Weichschott system 40
Weichschott system - wooden construction (wooden beams) 41
Mineral wool with fire-resistant coating and fire-resistant boards 42
Fire-resistant foam with stucco plaster
EI 60 (v
e
i↔o) S
43
Installation next to the wall/ceiling - mortar or gypsum + mineral wool
EI 90 (v
e
i↔o) S
44
Installation next to the wall/ceiling - mortar or gypsum 45
Outside gypsum wall construction
100
ISOVER Ultimate Protect - mortar or gypsum
EI 60 (v
e
i↔o) S
EI 90 (v
e
i↔o) S
46
ISOVER Ultimate Protect - Weichschott system 47
Mineral wool ROCKWOOL - Mineral wool with fire-resistant coating and fire-
resistant boards
EI 90 (v
e
i↔o) S
48
In sandwich wall construction 100 Weichschott system with fire-resistant boards
EI 90 (v
e
i↔o) S
49
In shaft wall Rigips
110 Mortar or gypsum
EI 90 (v
e
i↔o) S
51
80 Installation frame R1 52
In solid ceiling construction
110 - Concrete
125 - Aerated
concrete
Mortar or gypsum
EI 90 (h
o
i↔o) S
EI 120 (h
o
i↔o) S
53
2 dampers in one opening - mortar or gypsum
EI 90 (h
o
i↔o) S
54
Weichschott system 55
Mineral wool with fire-resistant coating and fire-resistant boards 56
Outside solid ceiling construction
110 - Concrete
125 - Aerated
concrete
ISOVER Ultimate Protect - mortar or gypsum (damper under ceiling)
EI 60 (h
o
i↔o) S
EI 90 (h
o
i↔o) S
57
ISOVER Ultimate Protect - mortar or gypsum (damper above ceiling) 58
Mineral wool ROCKWOOL - mortar or gypsum
EI 90 (h
o
i↔o) S
59
Concreting 60
Installation frame in solid wall
construction
100 (R1), 150 (R2) Installation frame R1, R2
EI 90 (v
e
i↔o) S
63
100 (R3), 150 (R4) Installation frame R3, R4 72
100
Installation frame R5 75
2 dampers in one opening - installation frame R1 64
100 (R1), 150 (R2) Installation next to the wall/ceiling - installation frame R1, R2 65
100 Installation next to the wall/ceiling - installation frame R5 76
Installation frame outside solid
wall construction
100
Insulation from fire-resistant boards - mortar or gypsum - installation frame R6
EI 90 (v
e
i↔o) S
82
Installation frame in gypsum wall
construction
100 (R1), 150 (R2) Installation frame R1, R2
EI 90 (v
e
i↔o) S
66
100
Installation frame R5 77
2 dampers in one opening - installation frame R1 67
100 (R1), 150 (R2) Installation next to the wall/ceiling - installation frame R1, R2 68
100
Installation next to the wall/ceiling - installation frame R5 78
Flexible ceiling - installation frame R7 85-86
Installation frame in solid ceiling
construction
110 - Concrete (R1)
150 (R2)
Installation frame R1, R2
EI 90 (h
o
i↔o) S
69
110 - Concrete (R3)
150 (R4)
Installation frame R3, R4 73
110 - Concrete
125 - Aerated
concrete
Installation frame R5 79
150 2 dampers in one opening - installation frame R2 70
Installation frame outside solid
ceiling construction
110 - Concrete
125 - Aerated
concrete
Concreting - installation frame R5
EI 90 (h
o
i↔o) S
80
Insulation from fire-resistant boards - mortar or gypsum - installation frame R6
83
