M&R CHALLENGER II Series User Manual

E 300 Operator Interface Logic Diagram
M&R Printing Equipment, Inc. - Glen Ellyn, Illinois
60
MAIN MENU SCREEN
PLC Identity No.
Program Version No.
MTA No.
COUNTERS
Shift Counter
Job Counter
Total Counter
Speed (Doz/hour)
TIMERS
Index
Flash
Quartz
>Preheat
OPTIONS
>Revolver Mode
Rotation CCW/CW
Index
Skip No T-Shirt Sensor
Pallet Size
Flash: ENTER
181716151413121110987654321
- - - - - - - - - - - - - - - -
Servo Offset:
End Position: 0.000”
Strt Position: 0.000”
GLUE APPLICATOR
Spray 1 Revln Only: OFF
Spray Every: 0 Revolution
Front Delay: 0.01 [s] Duration: 0.00
[s]
Rear Delay: 0.01 [s] Duration: 0.00 [s]
Revolution #: 0 Pallet #: 0
Oiler
Oil Every: 20 indexes
Index No.: 0
Manual Oiler: OFF
Ink Dip
Ink Dip Every: 999
Duration: 0.70 [s]
REVOLVER MODE
>Revolver Mode: OFF
>Index Delay: OFF
>Wait
>Enter Program
Revolution No.:
181716151413121110987654321
Pallet No.: 0
Job No.: Date: 00/00/00 00:00
Job Clear: OFF
Alarm Enabled: OFF
HARDWARE TEST
>Panel Test
>Proximities Test
>Motion Card Test
>Servo Drive Test
>Servo/Motion CArd History
>Other Tests
PANEL TEST
PROXIMITIES TEST
Front Proximities:
181716151413121110987654321
- - - - - - - - - - - - - - - -
Rear Proximities:
181716151413121110987654321
- - - - - - - - - - - - - - - -
Index On Prox: OFF
Lock Off Prox: OFF
Lift Up Prox: OFF
Double Index Prox: OFF
Home Postn Prox: OFF
MOTION CARD TEST
Motion Card Error: 0
Motion Card Warning:0
Reset: OFF
Servo Position: 0
Jog Forward: Off Jog Reverse: Off
X AD75 Ready: 0
Start Completed: OFF
Busy: OFF
Positioning Cmpltd: OFF
Error: OFF
M Code: OFF
Y Postioning Start: OFF
Axis Stop: OFF
Forward Jog Start: OFF
Reverse Jog Start: OFF
PC Ready: OFF
Drive Unit Ready: OFF
Zero Point Signl: OFF
In Positn Signl: OFF
Near Zero Point: OFF
Stop Signal: OFF
Upper Limit: OFF
Lower Limit: OFF
External Start: OFF
Speed/Position: SPD
In Zone: OFF
Home Pstn Requst: OFF
Home Pstn Cmpltd: OFF
Axis Warning: OFF
Speed Change: OFF
Abslt Pnt Ovrflw: OFF
Abslt Pnt Unrflw: OFF
SERVO DRIVE MANUAL OPERATION
