MOTOR / TRANSMISSION
150AETJ
(150AETJC)
150AETJ3D
(150AETJC3D)
170AETJL ±
Wheel motor
- Type
Electric (SEPEX)-ISKRA -
- Power kW 2 x 4.5 -
- Voltage V 48 -
- S2 - temporary operation min 60 -
- S3 - alternate operation % 100 -
Wheel reduction gear
- Supplier
BONFIGLIOLI -
- Reduction ratio 51.8 -
Steering/directional wheels - front/rear 2 / 0 -
Drive wheels - front/rear 0 / 2 -
Wheels (600X190)
- Supplier
SOLIDEAL / CAMSO -
- Dimensions: external Ø x width mm 600 x 190 -
- Inflation Solid tire -
Wheels (27X10X12)
- Supplier
SOLIDEAL / CAMSO -
- Dimensions: external Ø x width mm 700 x 246 -
- Inflation Foam -
ELECTRIC PUMP
150AETJ
(150AETJC)
150AETJ3D
(150AETJC3D)
170AETJL ±
Engine
- Type
Electric-ISKRA -
- Power kW 3.7 -
- Voltage V 48 -
- Current A 100 5%
- S2 - temporary operation min 18 2%
- S3 - alternate operation % 30 2%
Pump
- Type
Gear pump-CASAPPA -
- Cubic capacity cm³ 8.25 -
BRAKE
150AETJ
(150AETJC)
150AETJ3D
(150AETJC3D)
170AETJL ±
- Type of brake
Negative -
- Type of control Hydraulics -
- Braked wheels Rear wheels -
- Brake release (freewheel mode) Yes, manual -
- Braking torque N.m 86 5%
HYDRAULIC CIRCUIT
150AETJ
(150AETJC)
150AETJ3D
(150AETJC3D)
170AETJL ±
Distributor
- Type
BOSCH-REXROTH -
- Maximum pressure bar 210 5
Turntable motor
- Type
BONFIGLIOLI -
- Reduction ratio 7.2 -
BACKUP PUMP
150AETJ
(150AETJC)
150AETJ3D
(150AETJC3D)
170AETJL ±
Type
Manual -
Cubic capacity cm³ 20 -
