ELECTRICAL SYSTEM
150AETJ
(150AETJC)
150AETJ3D
(150AETJC3D)
170AETJL ±
Battery (original equipment - standard)
- Quantity
2 -
- Type Traction-HAWKER / GNB -
- Capacity C5 Ah 240 -
- Capacity C20 Ah 300 -
- Rated voltage V 48 -
- Control system voltage V 24 -
- EARL cycle 44 (HAWKER) / 46 (GNB) -
Battery charger (original equipment)
- Type
IES -
- Maximum current A 30 -
- Rated voltage V 48 -
- Phase progression type I1-P-U-I2 -
DIMENSIONS
150AETJ
(150AETJC)
150AETJ3D
(150AETJC3D)
170AETJL ±
Working height= maximum height of the basket floor (F2)+
2,000mm (wheels 600X190)
mm
14,985 16,905 1%
Working height= maximum height of the basket floor (F2)+
2,000mm (wheels 27X10X12)
mm 15,020 16,945 1%
Working reach = max. reach (A3) + 500mm mm 7,605 9,430 1%
Basket
- External dimensions (length x width) mm
1200 x 922 1%
- Floor dimensions (length x width) mm 1191 x 766 1%
- Rotation angle - right/left ° 66 / 59 1%
Jib angle - up/down ° 65 / 65 1%
Jib rotation angle - right/left ° - 70 / 70 - 1%
Turntable rotation angle ° 355 1%
Other dimensions, eDIMENSIONS AND DIAGRAM)
NOISE AND VIBRATION
150AETJ
(150AETJC)
150AETJ3D
(150AETJC3D)
170AETJL ±
Sound power level LwA dB
<70 -
Vibrations affecting body in the basket m/s² 0.52 0.66 -
EQUIPMENT
150AETJ
(150AETJC)
150AETJ3D
(150AETJC3D)
170AETJL ±
Multi-function display
Standard -
Low battery alarm Standard -
Tool box in basket Standard -
User interface - diagnostic aid Standard -
Battery cut-off Standard -
Built-in battery charger Standard -
Cover for basket control panel Option -
Orange flashing light Option -
All movements alarm Option -
Driving/steering alarm Option -
230V electric power socket in the basket Option -
Working light Option -
Secondary protection system SPS - first version "SafeManSystem" Option -
Secondary protection system SPS - second version Option -
Batteries "EXIDE" 48V 360A Option -
Batteries "HAWKER" 48V 360A Option -
Batteries "ENERSYS" 48V 300A Option -
Gel batteries "EXIDE" 48V 275A Option -
2 - 20
647536 (26/11/2020) 150 AETJ/AETJ 3D - 150 AETJ C/AETJ C 3D - 170 AETJ L
