2-65
18” WHEELS OPTION
- This option is recommended for use on very difficult terrain.
The use of the 18” wheels option requires modification of the
translation speeds by adjustment of certain programming
parameters.
The empty weight of the nacelle changes with the use of 18”
wheels. The manufacturer’s data plate must be replaced to
show the new empty weight (see CHARACTERISTICS section).
The height of the nacelle changes with the use of 18” wheels
(see CHARACTERISTICS section).
SAFE MAN SYSTEM
The safe man system option is a system used to disable all of the basket control panel
controls when activated by the nacelle user.
OPERATION
- Each time the nacelle is switched on, a system test is performed: there is a beep and
the blue warning light flashes (Fig. C).
- If the pressure-sensitive edge is pressed (Fig. A), the system cuts all of the nacelle
controls. The blue warning light and an audible alarm are activated.
- If the user releases the pressure-sensitive edge:
By pressing the nacelle “OFF” rearming button (Fig. B) once, the user can regain control
of the nacelle controls. The blue warning light and the audible alarm are turned off.
- If the user continues to press on the pressure-sensitive edge:
By pressing the nacelle “OFF” rearming button (Fig. B) once, the user can regain
control of the nacelle controls. The blue warning light and the audible alarm are
turned off when the user releases the pressure-sensitive edge.
A
B
647414 EN (27/05/2015)
