4- EMERGENCY STOP
This red mushroom-headed switch cuts off all the machine’s movements in the event of
an anomaly or any danger.
- Press the knob to cut off the movements.
- Turn the knob a quarter turn to the right to restore the power supply (the switch
automatically returns to its initial position).
In all cases, this command takes precedence, even when the
movemen
ts are being controlled from the basket control station.
If the Emergency Stop is activated, the movements may stop very
suddenly.
Do not use the emergency stop to simply shut down the lifting
platform. Otherwise, rearm it immediately as no action can be
performed on the control panels at ground level or in the basket.
5 - LOW-TEMPERATURE ENGINE START-UP AID
This selector switch has two positions to be selected according to the ambient air
temperature.
1 : SUN POSITION
- If the temperature is over - 10°C, start the engine at tickover rpm.
2 : SNOW POSITION
- If the temperature is less than around - 10°C, set the selector switch to this position
before starting: the engine will be held at maximum rpm (only for the first start of the
day).
- Leave the engine at maximum rpm for 30 to 60 seconds, depending on the temperature
(no movement is possible during this time).
- Switch the selector switch from SNOW to SUN position and the rpm drop to tickover
level (normal position, warm engine).
Position 1
Position 2
4
5
647414 EN (27/05/2015)
