2-40
19 - BASE EMERGENCY PUMP BUTTON
- This button starts the emergency pump, which enables you to make all the basket’s
movements and return to the ground in the event of a breakdown occurring (see the:
RESCUE PROCEDURE section).
Only use this if the engine or the electrical system has broken down.
20 - FUEL COCK
- The fuel cock (20) located on the diesel filter must be in the “ON” position as shown
opposite before starting the engine.
- The “OFF” position on the fuel cock shuts off the fuel supply to the engine.
676992
20
Diesel fuel cock
opening area
Diesel fuel cock
shut-off point
20
19
647414 EN (27/05/2015)
