2-27
DIAGRAM 180 ATJ 2 E3 - 180 ATJ 2 E3 RC
G1
234567823
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
0123456789
G3
10
G4
11
H4
1
G5
2
H5
10 11
3
H1
H2
G2
H3
H6
9
G1 3552
G2 4537
G3 10038
G4 10065
G5 9063
H1 16120
H2 14577
H3 7556
H4 2275
H5 58
H6 7434
647414 EN (27/05/2015)
