2-26
DIAGRAM 160 ATJ E3 - 160 ATJ E3 RC - 160 ATJS E3
G1
H1H2
G2
H3
G3
G5
G4
H4
H5
H6
10
3
11
13
15
16
17
109876
12
14
21013
3
1
2
4
5
6
7
8
42 5
9
223453 789106
G1 2910
G2 3890
G3 7795
G4 7820
G5 6820
H1 14010
H2 12470
H3 7505
H4 2225
H5 205
H6 7380
647414 EN (27/05/2015)
