24
MARA PIGGYBACK SERVICE MANUAL
13
14
15
shaft and air piston assembly
Reinstall the rebound shaft
into the main shaft.
Orient at side of the spring
towards the upper end of the
rebound needle against the
two shims.
Replace the bottom out
bumper O-Ring (101-1150-
0300) above the air piston.
