27
MARA PIGGYBACK SERVICE MANUAL
Next install the white PTFE
back-up ring, tting in the
same groove. Note the back-
up ring must be to the outside
of the quad-ring
Install the wiper seal, with the
narrow lip facing externally.
Replace the King Can sleeve
seals in three places (if using
a full King Can, only the two
outer seals will be used.)
(100-030). Apply a few dabs
of grease to the middle seal
gland, and install back-up ring
(08-36360). Apply Slickoleum
grease to the ID of the
cleaned King Can sleeve.
5
4
6
Air can service
