8
MARA PIGGYBACK SERVICE MANUAL
7
With a plastic pick remove
quad-ring seal.
A small side-cutter can be
used to rst partially cut the
large piston ring, then break it
to remove. Be careful not to
damage the groove.
8
9
Remove the Piggyback
Reservoir cap by unthreading
it counter-clockwise.
SHOCK TEARDOWN
