9
MARA PIGGYBACK SERVICE MANUAL
10
Thread on shock pump, using
the pump’s pressure release
button, release all air. Then
depress Schrader valve with
a small tool a few times to
ensure all air is released.
Remove the valve core.
Use a freewheel removal tool
(example: Park Tool FR-1) to
remove the Reservoir End Cap.
11
12
Place a catch basin under the
shock to catch oil. Use the
air can / reservoir wrench
(PN 142-37512-K033) to
unthread the shock reservoir.
(Alternative: use a 30mm
wrench)
SHOCK TEARDOWN
CAUTION
Do not proceed to the next
step without completely
depressurizing reservoir.
