CHARACTERISTICS MI-X 50L D C ST3A S2 MI-X 60 D C ST3A S2 MI-X 70 D C ST3A S2
NOTE: The specifications given are not binding on the manufacturer and can be modified without prior notification.
DESIGNATION
1.1
Manufacturer MANITOU
1.2
Model type MI-X 50L D MI-X 60 D MI-X 70 D
1.3
Propulsion: battery, diesel, petrol, LPG, mains Diesel
1.4
Type of operation: manual, pedestrian, standing, seated Seated
1.5
Rated capacity/load on forks (basic capacity)
Q (t)
567
1.6
Centre of gravity of load
c (mm)
600
1.8
Distance from the load bearing surface to the centre of the front axle
x (mm)
598 598 603
1.9
Wheelbase
y (mm)
2300
WEIGHT
2.1
Weight of truck in working order
kg
8295 8825 9595
2.2
Front axle load laden
kg
11500 13000 14830
2.2.1
Rear axle load laden
kg
1795 1825 1765
2.3
Front axle load unladen
kg
4080 3960 3910
2.3.1
Rear axle load unladen
kg
4215 4865 5685
RUNNING CARRIAGE
3.1
Tyre equipment: bandage (V), super-elastic (SE), pneumatic (L) SE
3.2
Size of front wheels
“ or mm
8.25-15-14PR
3.3
Size of rear wheels
“ or mm
8.25-15-14PR
3.5
Number of front wheels (x = drive wheel) 4x
3.5.1
Number of rear wheels (x = drive wheel) 2
3.6
Front wheel gauge (middle of wheels)
b10
(mm)
1489
3.7
Rear wheel gauge (middle of wheels)
b11
(mm)
1700
DIMENSIONS
4.1
Tilt of mast forward
α (°)
6
4.1.1
Tilt of mast backward
β (°)
12
4.2
Height of mast lowered
h1 (mm)
2500
4.3
Normal free lift
h2 (mm)
160
4.4
Lift height
h3 (mm)
3000
4.5
Height of extended mast
h4 (mm)
4420
4.7
Height of driver protection (cab)
h6 (mm)
2430
4.8
Height of seat
h7 (mm)
1350
4.12
Height of towing coupling
h10
(mm)
710
4.19
Total length
l1 (mm)
4719 4729 4804
4.20
Length of forks at heel
l2 (mm)
3499 3509 3584
4.21
Overall width
b1 (mm)
1990
4.22
Section of fork arms
s/e (mm)
150 / 60 150 / 60 150 / 65
4.22.2
Length of fork arms
l (mm)
1220
4.23
Fork carriage in accordance with DIN 15 173 A/B FEM 4A
4.24
Width of fork carriage (with load back-rest)
b3 (mm)
1700
4.31
Ground clearance of mast
m1 (mm)
190
4.32
Ground clearance at centre of wheel-base
m2 (mm)
270
4.33
Aisle width for 1,000x1,200 pallet widthways
Ast (mm)
5137 5167 5242
4.34
Aisle width for 800x1,200 pallet lengthways
Ast (mm)
5272 5302 5377
4.35
Turning radius
Wa (mm)
3230 3260 3330
4.36
Inner turning radius
b13 (mm)
1222
2-10
647650 (19/02/2018)
M
I-X 50L/60/70 D C ST3A S2 / MI 50L/60/70 D ST3B S2 / MI 50L/60/70 G S2
