Manitou MI-X 50L D C ST3A S2 User Manual

- CHECK Engine oil level.......................................................................... 3-14
- CHECK MI . . D ST3B S2 Belt tension ............................................................................. 3-18
- CHECK Gear box seal ........................................................................... 3-19
- CHECK Front axle differential seal ............................................................... 3-19
- CHECK Tyre pressures........................................................................... 3-19
- CHECK Wheel nut torques ...................................................................... 3-19
- CHECK Hydraulic oil level ....................................................................... 3-20
- CHECK Washer fluid level (option)............................................................... 3-20
- CLEAN Dry air filter cartridge ................................................................... 3-21
- CLEAN Radiator core ........................................................................... 3-21
- CLEAN Condenser core (option)................................................................. 3-22
- GREASE General greasing........................................................................ 3-22
- ADJUST Tension and alignment of the mast lifting chains .......................................................... 3-23
- GREASE Mast lifting chains....................................................................... 3-24
- REPLACE Engine oil............................................................................... 3-24
- REPLACE Engine oil filter.......................................................................... 3-24
- REPLACE MI-X . . D C ST3A S2 Fuel filter ............................................................................... 3-26
- REPLACE MI-X . . D C ST3A S2 Fuel pre-filter ........................................................................... 3-27
- CHECK MI . . G S2 Engine idling speed *.................................................................... 3-27
- CHECK MI . . G S2 Ignition setting * ........................................................................ 3-27
- CHECK MI . . G S2 Spark plug *............................................................................. 3-27
- CHECK MI . . G S2 Ignition rotor and head * ................................................................ 3-27
- CHECK MI . . G S2 LPG carburettor * ....................................................................... 3-27
- CHECK MI . . G S2 LPG pressure relief valve * ............................................................... 3-27
- CHECK Speeds of hydraulic movements * ....................................................... 3-27
- CHECK Condition of hoses and flexible pipes *................................................... 3-27
- CHECK Condition of cylinders (leakage, rods) * .................................................. 3-27
- CHECK Fork wear *.............................................................................. 3-27
- CHECK Safety belt .............................................................................. 3-28
- REPLACE MI . . D ST3B S2 Fuel filter ............................................................................... 3-29
- REPLACE MI . . D ST3B S2 Fuel pre-filter ........................................................................... 3-29
- CHECK Engine speeds *......................................................................... 3-33
- CHECK Engine valve clearances *................................................................ 3-33
- CHECK Engine silent blocks *.................................................................... 3-33
- CHECK Gear box silent blocks *.................................................................. 3-33
- CHECK Condition of wheels and tyres *.......................................................... 3-33
- CHECK Brake *.................................................................................. 3-33
- CHECK Condition of wiring harnesses and cables *............................................... 3-33
- CHECK Lights and signals * ..................................................................... 3-33
- CHECK Warning indicators * .................................................................... 3-33
- CHECK Condition of the rear view mirrors *...................................................... 3-33
- CHECK Cab structure *.......................................................................... 3-33
- CHECK Frame structure * ....................................................................... 3-33
- CHECK Condition of attachments *.............................................................. 3-33
* Consult your dealer.
MANDATORY FIRST 500 HOURS OR 6 MONTHS SERVICE
FIRST 500 HOURS BEFORE THE FIRST 6 MONTHS
- If the lift truck completes its first 500 hours of service before the first 6 months are up, carry out the mandatory service
and the 500 hour periodic maintenance (
n
500 HOURS - PERIODIC MAINTENANCE).
FIRST 6 MONTHS BEFORE THE FIRST 500 HOURS
- If the lift truck has not completed 500 hours of service in the first 6 months, just carry out the mandatory service.
Â
MANDATORY SERVICE
3 - 5
647650 (19/02/2018)
M
I-X 50L/60/70 D C ST3A S2 / MI 50L/60/70 D ST3B S2 / MI 50L/60/70 G S2
