Manitou MI-X 50L D C ST3A S2 - Page 68

Ân
500H - PERIODIC MAINTENANCE - EVERY 500 HOURS OF SERVICE
- GREASE Mast lifting chains....................................................................... 3-24
- REPLACE Engine oil............................................................................... 3-24
- REPLACE Engine oil filter.......................................................................... 3-24
- REPLACE
MI-X . . D C ST3A S2 Fuel filter ............................................................................... 3-26
- REPLACE MI-X . . D C ST3A S2 Fuel pre-filter ........................................................................... 3-27
- CHECK MI . . G S2 Engine idling speed *.................................................................... 3-27
- CHECK MI . . G S2 Ignition setting * ........................................................................ 3-27
- CHECK MI . . G S2 Spark plug *............................................................................. 3-27
- CHECK MI . . G S2 Ignition rotor and head * ................................................................ 3-27
- CHECK MI . . G S2 LPG carburettor * ....................................................................... 3-27
- CHECK MI . . G S2 LPG pressure relief valve * ............................................................... 3-27
- CLEAN MI . . G S2 LPG pressure relief valve filter * .......................................................... 3-27
- BLEED MI . . G S2 LPG vaporiser pressure regulator * ....................................................... 3-27
- CHECK Speeds of hydraulic movements * ....................................................... 3-27
- CHECK Condition of hoses and flexible pipes *................................................... 3-27
- CHECK Condition of cylinders (leakage, rods) * .................................................. 3-27
- CHECK Fork wear *.............................................................................. 3-27
* Consult your dealer.
Âo
1000H - PERIODIC MAINTENANCE - EVERY 1000 HOURS OF SERVICE OR 2 YEARS
ALSO PERFORM THE 500 HOUR PERIODIC MAINTENANCE OPERATIONS.
- CHECK Safety belt .............................................................................. 3-28
- LUBRICATE Service brake pedal axle................................................................. 3-28
- REPLACE MI . . D ST3B S2 Fuel filter ............................................................................... 3-29
PERIODIC MAINTENANCE
MAINTENANCE SCHEDULE
ÄORÄ
WHEN DUE
Â
FIRST 6 MONTHS FIRST 500 HOURS
500 H
or 1 YEAR
1000 H
or 2 YEARS
1500 H
or 3 YEARS
2000 H
or 4 YEARS
PERIODIC MAINTENANCE
Â
MANDATORY SERVICE
MANDATORY SERVICE
+
n
nn
+
onn
+
o
+
p
MACHINE COUNTER
Â
DATE OF SERVICING
Â
WHEN DUE
Â
2500 H
or 5 YEARS
3000 H
or 6 YEARS
3500 H
or 7 YEARS
4000 H
or 8 YEARS
4500 H
or 9 YEARS
5000 H
or 10 YEARS
5500 H
or 11 YEARS
PERIODIC MAINTENANCE
Â
nn
+
onn
+
o
+
pn n
+
on
MACHINE COUNTER
Â
DATE OF SERVICING
Â
WHEN DUE
Â
6000 H
or 12 YEARS
6500 H
or 13 YEARS
7000 H
or 14 YEARS
7500 H
or 15 YEARS
8000 H
or 16 YEARS
8500 H
or 17 YEARS
9000 H
or 18 YEARS
PERIODIC MAINTENANCE
Â
n
+
o
+
pn n
+
onn
+
o
+
pn n
+
o
MACHINE COUNTER
Â
DATE OF SERVICING
Â
3 - 6
647650 (19/02/2018)
