Manitou MLT 845 120 LSU 3-E3 Series User Manual

3-213-21

C5
C5
22
 11
C6C6
22
11
C7C7
11
C5 - AIR C5 - AIR CONDITONING FILCONDITONING FILTER (OPTION AIR TER (OPTION AIR CONDITIONING)CONDITIONING)
CHANGECHANGE
- Lift up protective casing - Lift up protective casing 1 (fig. C5).1 (fig. C5).
-- Lift out the air conditioning filter 2 (fig. C5) and fit new replacement fLift out the air conditioning filter 2 (fig. C5) and fit new replacement filter (see: 3 -ilter (see: 3 -
MAINTENANCE: FILTERS CARTRIDGES AND BELTS).MAINTENANCE: FILTERS CARTRIDGES AND BELTS).
- Refit the protective casing.- Refit the protective casing.
C6 - FRONT AND REAR C6 - FRONT AND REAR AXLE DIFFERENTIAL OIL LEVELAXLE DIFFERENTIAL OIL LEVEL
CHECKCHECK
Place the lift truck on level ground with the I.C. engine stopped.Place the lift truck on level ground with the I.C. engine stopped.
- Remove level plug 1 (fig. C6). The oil should be flush with the edge of the hole.- Remove level plug 1 (fig. C6). The oil should be flush with the edge of the hole.
-- If necessary, add oil (see: 3 - MIf necessary, add oil (see: 3 - MAINTENANCE: LUBRICANTS AND FUEL) by tAINTENANCE: LUBRICANTS AND FUEL) by the filler port 2he filler port 2
(fig. C6).(fig. C6).
- Replace and tighten the level plug 1 (fig. C6) (tightening torque 34 to 49 N.m).- Replace and tighten the level plug 1 (fig. C6) (tightening torque 34 to 49 N.m).
C7 - FRONT AND REAR WHEELS REDUCERS OIL LEVELC7 - FRONT AND REAR WHEELS REDUCERS OIL LEVEL
CHECKCHECK
Place the lift truck on level ground with the I.C. engine stopped.Place the lift truck on level ground with the I.C. engine stopped.
- Check the level on - Check the level on each front wheel reducer.each front wheel reducer.
- Place level plug 1 (fig. C7) in the horizontal position.- Place level plug 1 (fig. C7) in the horizontal position.
- Remove the level plug, the oil should be flush with the edge of the hole.- Remove the level plug, the oil should be flush with the edge of the hole.
-- If necessary, add oil (see: If necessary, add oil (see: 3 - MAINTENANCE: LUBRICANTS 3 - MAINTENANCE: LUBRICANTS AND FUEL) by the same hole.AND FUEL) by the same hole.
- Replace and tighten the level plug 1 (fig. C7) (tightening torque 34 to 49 N.m).- Replace and tighten the level plug 1 (fig. C7) (tightening torque 34 to 49 N.m).
- Repeat this operation on each rear - Repeat this operation on each rear wheel reducer.wheel reducer.
