R8 PRO SERVICE GUIDE
7
8
R8 PRO CASTING INSTALLATION
Thread the other lock-nut onto the spring shaft adapter.
Holding the lock-nut with a 14mm box wrench, use an 8mm
socket tighten the compression rod adapter to 35–40 in-lb
[3.95–4.5 Nm] by turning them counter-clockwise. Do not
overtighten, doing so can damage the threads.
Install the rebound knob using a 2mm Hex wrench. Add a
small drop of blue Loctite to the screw before installation to
prevent the screw from backing out during riding.
Note: Be sure to hold the knob still while removing the
screw. The damper adjuster may be damaged if the knob is
over torqued.
