31000 LUFFING JIB OPERATOR MANUAL SET-UP AND INSTALLATION
4
3
Information below from drawing A19443, Sheet 4 and 8:
On the #90 boom 10 m (32.8 ft) equalizer insert (A), attach the lower wire rope guide (B):
Step Action
Item Description
A #90 boom 10 m (32.8 ft) equalizer insert
(working configuration)
B Lower wire rope guide (working position).
