SET-UP AND INSTALLATION 31000 LUFFING JIB OPERATOR MANUAL
4-10 Published 07-23-15, Control # 078-03
9
Information below from drawing A19443, Sheet 8:
Use the Drum 6 rigging winch (C) to reeve the following:
• 50 mm load hoist wire ropes up to the wire rope guide on the wire rope guide (see Figure 4-7
).
• From Drum 5 to the #90 boom top as shown below:
Step Action
Item Description
A Drum 5 wire rope.
B Drum 6 winch wire rope.
C Drum 6 winch.
D Luffing jib wire rope guide (upper).
E Luffing jib wire rope guide (lower).
AB
C
D
E
FIGURE 4-10
