31000 LUFFING JIB OPERATOR MANUAL SET-UP AND INSTALLATION
4
3
Information below from drawing A19443, Sheet 28:
Boom up to allow the upper boom point (A) to hang vertically:
Step Action
FIGURE 4-82
Item Description
A Upper boom point.
B Drum 3 wire rope.
A
B
Boom up
Center of gravity
