ENGINE AND ENGINE SYSTEMS 5540F/YB5515 SERVICE MANUAL
6-22 Published 10-21-2010, Control# 198-04
Basic Dual Fuel System Troubleshooting Guide
NOTE: The following figures show items referenced in the
dual fuel troubleshooting guide.
FIGURE 6-19
p3032
Throttle Body
Actuator
LPG Mixer
Air Inlet
Fuel Injectors
Gasoline Inlet
Maximum LPG
Flow Adjustment
Air Temperature
Sensor
Dual Fuel System
FIGURE 6-20
p3034
Dual Fuel System
Air Inlet
Air Temperature
Sensor
Reference Only
