Manitowoc Grove 5540F

11-49
5540F/YB5515 SERVICE MANUAL STRUCTURALS
11
FIGURE 11-120
a2270
Winch Tension Roller Subassembly Cut-Away View
Item Description
1. Tension Roller Arm
2. Tension Spring (2)
3. Tension Roller Shaft
4. Tension Arm Shaft
5. Set Screw (2)
6. Washer (6)
7. Roller Bushing (2)
8. Spring Anchor (2)
9. Roller Rod End (2)
10. Nut (4)
Item Description
11. Lockwasher (8)
12. Capscrew (4)
13. Roll Pin (2)
14. Snap Ring (2)
15. Thrust Race (2)
16. Roller
17. Roll Pin (2)
18. Lever Arm (2)
19. Roller (2)
Reference Only
