HYDRAULIC SYSTEM 5540F/YB5515 SERVICE MANUAL
4-8 Published 10-21-2010, Control# 198-04
Lubrication of internal components is provided through
passages in the hydraulic pump body and grooves in the
pressure plates. A lip seal on the shaft and o-rings between
the sections prevent external leakage in the pump.
