Manitowoc Grove GRT880

4-13
Published 10/19/2017, Control # 618-00
GRT880 SERVICE MANUAL BOOM
4
GROVE
Item Description
101 BASE WELDMENT
102 ASSY BOOM CABLE GUIDE
103 WEAR PAD - ASSY
104 WEAR PAD - ASSY
105 WEAR PAD
106 WEAR PAD
107 PROTECTION STRIP
108 WEAR STRIP
109 WEAR PAD
110 SHIM FRONT
111 PLATE - CTR RETAINER
112 PLATE - SIDE RETAINER
113 RETAINER
114 SHIM
115 BLOCK STOP
116 BRACKET
117 BAR BENT KEEPER
118 COVER
119 F WASHER 1-1/8” HARD ASTM F-43
120 F WASHER 5/8” HARD ASTM F-436
121 F WASHER, 8 ST ISO 7089
122 L WASHER, 8 ST DIN 127B
123 L WASHER 10 -HRC44-51 DIN 127
124 F WASHER, 12 ST ISO 7089
125 L WASHER 12 -HRC44-51 DIN 127
126 HHCS FULL THREAD, 8 X 25 8.8
127 SBCS M10X25 SS ISO 7380
128 HSSS-FLAT M12X35 -45H
129 HHCS M12X45 8.8 ISO 4014
130 HHCS M12X40 8.8 ISO 4017
131 HHCS M12X80 8.8 ISO 4014
132 HHCS M16X40 10.9 ISO 4017
133 SHCS M16X50 10.9 ISO 4762
134 HHCS M30X60 10.9 ISO 4017
135 HEX NUT, 8 8 ISO 4032
136 HEX NUT M12 8 ISO 4032
137 HEX NUT M16 8 ISO 4032
138 HEX JAM NUT, 16-8 ISO 4035
139 HITCH PIN CLIP
140 F WASHER 3/4? HARD ASTM F-436-
141 HEX JAM NUT M12 04 ISO 4035
142 COVER
143 L WASHER 6 -HRC44-51 DIN 127B
144 HHCS M6X16 SS ISO 4017
145 HHCS M8X30 8.8 ISO 4017
201 TELE 1 SECTION WELDMENT
202 WEAR PAD
203 WEAR PAD
204 WEAR PAD - ASSY
205 WEAR PAD - ASSY
206 WEAR PAD
207 WEAR PAD
208 LUBRICANT HOSE L=420
209 WEAR PAD
210 PLATE RETAINER
211 PLATE RETAINER
212 SHIM REAR
213 PIN
214 PIN
215 PLATE KEEPER
216 RETAINER
217 SHIM
218 BLOCK STOP
219 SHIM FRONT
220 BRACKET
221 PLATE
222 FILL PLATE
223 FILL PLATE
224 SLIDER SUSTAGLIDE
225 SHCS-LOW M12X20 8.8-A3C DIN 79
226 ROLLER
227 ADAPTER 304-19509-1 M10X1/M10X
228 ELBOW, PUSH-IN 226-14123-3 WEK
229 PIPE UNION SV-06L/SW17 M12X1
231 F WASHER 1/2? HARD ASTM F-436
232 F WASHER 5/8? HARD ASTM F-436
233 F WASHER, 8 ST ISO 7089
234 L WASHER, 8 ST DIN 127B
235 F WASHER, 12 ST ISO 7089
236 L WASHER 12 -HRC44-51 DIN 127
237 HHCS M8X30 8.8 ISO 4017
238 HHCS M12X40 8.8 ISO 4017
239 HSSS-FLAT M12X35 -45H
241 HHCS M20X80 8.8 ISO 4017
242 SFHCS M10X20 10.9 ISO 10642
243 HHCS M12X90 10.9 ISO 4014
244 HHCS M16X40 10.9 ISO 4017
245 SHCS M16X50 10.9 ISO 4762
Item Description
Reference Only
