Manitowoc Grove GRT880

BOOM GRT880 SERVICE MANUAL
4-14
Published 10/19/2017, Control # 618-00
246 HEX NUT, 8 8 ISO 4032
247 HEX NUT M12 8 ISO 4032
248 HEX NUT M16 8 ISO 4032
249 HEX JAM NUT, 16-8 ISO 4035
250 HEX NUT M20 8 ISO 4032
251 HEX JAM NUT M12 04 ISO 4035
252 SHAFT
253 COTTER PIN 0.13X1.75’’ ST
254 SHIM
301 TELE 2 SECTION WELDMENT
302 SHEAVE ASSY
303 LUBRICANT HOSE L=500
304 WEAR PAD
305 WEAR PAD
306 WEAR PAD - ASSY
307 WEAR PAD - ASSY
308 WEAR PAD
309 WEAR PAD
310 WEAR PAD
311 PLATE RETAINER
312 PLATE RETAINER
313 PIN MOUNTING
314 PIN CYL MOUNT
315 GUARD CABLE KEEPER
316 BLOCK STOP
317 SHIM REAR
318 SHIM FRONT
319 RETAINER
320 SHIM
321 RETAINER
322 PLATE KEEPER
323 BRACKET
324 FILL PLATE
325 FILL PLATE
326 SLIDER SUSTAGLIDE
327 SHCS-LOW M12X20 8.8-A3C DIN 79
328 PROTECTION STRIP
329 ADAPTER 304-19509-1 M10X1/M10X
330 ELBOW, PUSH-IN 226-14123-3 WEK
331 PIPE UNION SV-06L/SW17 M12X1
334 F WASHER 5/8? HARD ASTM F-436
335 THRUST WASHER
336 F WASHER, 8 ST ISO 7089
337 L WASHER, 8 ST DIN 127B
Item Description
338 F WASHER, 12 ST ISO 7089
339 L WASHER 12 -HRC44-51 DIN 127
340 HHCS M8X30 8.8 ISO 4017
341 HSSS-FLAT M12X35 -45H
342 HHCS M12X40 8.8 ISO 4017
343 HHCS M12X80 8.8 ISO 4014
344 HHCS M20X80 8.8 ISO 4017
346 SFHCS M10X20 10.9 ISO 10642
347 SFS M12X30 -10.9 ISO 10642
348 HHCS M16X40 10.9 ISO 4017
349 SHCS M16X50 10.9 ISO 4762
350 HEX NUT, 8 8 ISO 4032
351 HEX NUT M12 8 ISO 4032
352 HEX NUT M16 8 ISO 4032
353 HEX JAM NUT, 16-8 ISO 4035
354 HEX NUT M20 8 ISO 4032
355 HEX JAM NUT M12 04 ISO 4035
356 WEAR PAD
401 TELE 3 SECTION WELDMENT
402 LUBRICANT HOSE L=420
403 SHIM REAR
404 RETAINER CABLE
405 WEAR PAD
406 WEAR PAD
407 SLIDER
408 FILL PLATE T=2 ALMG3
409 FILL PLATE T=1 ALMG3
410 ADAPTER 304-19509-1 M10X1/M10X
411 ELBOW, PUSH-IN 226-14123-3 WEK
412 PIPE UNION SV-06L/SW17 M12X1
414 SHCS-LOW M12X20 8.8-A3C DIN 79
415 F WASHER, 8 ST ISO 7089
416 L WASHER, 8 ST DIN 127B
417 HHCS M8X16 SS ISO 4017
418 HHCS M20X80 8.8 ISO 4017
419 HEX NUT M20 8 ISO 4032
501 TELE, 180/155X9500
502 TELE, 180/155X9572
503 WELDMENT CYL MOUNT
504 PLATE - L.H.
505 WEAR PAD
506 WELDMENT, SHEAVE HEAD
507 WELDMENT
508 PLATE - R.H.
