1-5
Published 10/19/2017, Control # 618-00
GRT880 SERVICE MANUAL INTRODUCTION
1
GROVE
Description
CG to CL
Rear Bogie
cm (in)
Weight
kg (lb)
Front Axle
kg (lb)
Rear Axle
kg (lb)
Maximum Axle Loads Allowed 31752 (70000) 31752 (70000)
Maximum Axle Loads Allowed while Towing 27216 (60000) 27216 (60000)
Maximum Tire Loads Allowed 32006 (70560) 32006 (70560)
Standard Carrier Assy (4x4) + All Fluids 188.52 (74.22) 21532 (47469) 9627 (21224) 11905 (26245)
Superstructure Assy w/Cab, Main Hoist + cable &
IPO Cwt"
78.41 (30.87) 6318 (13929) 1175 (2590) 5143 (11339)
Removeable Counterweight - 22,000 lb" -157.48 (-62.00) 10000 (22046) -3735 (-8234) 13735 (30280)
Boom Assy, 2/5 Sheaves, Lift Cyl Upr Pin & Pivot Pin" 600.08 (236.25) 10577 (23318) 15053 (33186) -4476 (-9868)
Lift Cylinder & Lower Shaft 493.67 (194.36) 1169 (2577) 1369 (3017) -200 (-440)
Complete Basic Machine: 12.6 - 41 m (41 - 135 ft)
4-Section Boom, Cummins QSB6.7 Tier 4F Final
Engine, 29.5x25 (34 ply) Tires, Main Hoist w/214 m
(702 ft) of 19 mm (3/4 in) 35x7 cable, Full Fuel and
Hydraulic Oil"
199.69 (78.62) 49596
(109339)
23489 (51783) 26107 (57556)
Add to Basic Machine Weight
10.1 - 17.1 m (33 - 56 ft) Bi-fold Manual Boom
Extension
798.63 (314.42) 1324 (2919) 2508 (5529) -1184 (-2610)
10.1 m (33 ft) Fixed Manual Boom Extension 884.12 (348.08) 945 (2083) 1981 (4368) -1036 (-2285)
Boom Extension Carrier Brackets (Bolt On) 704.22 (277.25) 187 (413) 313 (690) -126 (-277)
Aux Boom Nose - installed 1299.41 (511.58) 59 (130) 182 (401) -123 (-271)
11 t (12 ton) Overhaul Weight - tied to O/R Box 675.64 (266.00) 294 (648) 471 (1038) -177 (-390)
75 t (83 ton) Hookblock (5 sheave) - stowed in tray 421.64 (166.00) 594 (1310) 594 (1310) 0 (0)
60 t (66 ton) Hookblock (5 sheave) - stowed in tray 421.64 (166.00) 581 (1281) 581 (1281) 0 (0)
45 t (50 ton) Hookblock (3 sheave) - stowed in tray 421.64 (166.00) 450 (992) 450 (992) 0 (0)
26 t (29 ton) Hookblock (1 sheave) - stowed in tray 421.64 (166.00) 323 (712) 323 (712) 0 (0)
Rubber Mat in Front Stowage Tray 439.42 (173.00) 25 (56) 26 (58) 0 (-2)
Driveline Retarder 226.06 (89.00) 546 (1203) 293 (645) 253 (558)
Counterweight Stand -167.64 (-66.00) 118 (260) -47 (-103) 165 (363)
Air Conditioning - Carrier 50.80 (20.00) 9 (19) 1 (2) 8 (17)
Air Conditioning - Superstructure 70.61 (27.80) 31 (69) 5 (12) 26 (57)
360 Degree Swing Lock 261.11 (102.80) 31 (69) 20 (43) 12 (26)
Driver 225.81 (88.90) 113 (250) 61 (134) 53 (116)
Cold Weather Package - Carrier (-29°) 20.32 (8.00) 107 (236) 5 (11) 102 (225)
Cold Weather Package - Carrier (-40°) 154.94 (61.00) 168 (370) 62 (136) 106 (234)
Cold Weather Package - S/S (-29° or -40°) 146.81 (57.80) 34 (76) 12 (26) 23 (50)
CE Components - Carrier 187.96 (74.00) 47 (104) 21 (46) 26 (58)
CE Components - Superstructure 98.55 (38.80) 116 (255) 27 (60) 88 (195)
Substitutions and Removals
SUB: Aux Hoist (replace IPO cwt with aux hoist +
cable)
-147.83 (-58.20) 431 (950) -151 (-333) 582 (1283)
SUB: Tier 3 Engine -101.60 (-40.00) -197 (-435) 48 (105) -245 (-540)
