Manitowoc Grove GRT880

INTRODUCTION GRT880 SERVICE MANUAL
1-6
Published 10/19/2017, Control # 618-00
SUB: Synthetic Rope on Main Hoist (220 m (722 ft) of
22 mm (7/8 in) K-100)
-76.71 (-30.20) -318 (-702) 58 (128) -376 (-830)
SUB: Synthetic Rope on Aux Hoist (220 m (722 ft) of
22 mm (7/8 in) K-100)
-163.07 (-64.20) -318 (-702) 123 (271) -441 (-973)
REM: Main Hoist cable (214 m (702 ft) of 19 mm (3/4
in) 35x7)
-76.71 (-30.20) -388 (-856) 71 (156) -459 (-1012)
REM: Aux Hoist cable (214 m (702 ft) of 19 mm (3/4
in) 35x7)
-163.07 (-64.20) -388 (-856) 150 (331) -538 (-1187)
Description
CG to CL
Rear Bogie
cm (in)
Weight
kg (lb)
Front Axle
kg (lb)
Rear Axle
kg (lb)
Reference Only
