4-59
Published 10/19/2017, Control # 618-00
GRT880 SERVICE MANUAL BOOM
4
GROVE
FIGURE 4-132
Item Description
1 Flat Washer
2 Capscrew
3 Lift Cylinder Foot Pin
4Shim - 1mm
5Shim - 2mm
6 Spacer
7Nut
8 Setscrew
Item Description
1 32 4 5 6
3
7
8
9080-6
9080-7
Reference Only
