BOOM GRT880 SERVICE MANUAL
4-60
Published 10/19/2017, Control # 618-00
FIGURE 4-133
Item Description
1 Spacer
2 Spacer
3 Flat Washer
4 Lock Washer
5 Capscrew
6 Pivot Pin Plate
7 Cylinder Pivot Pin
Item Description
1 2 4 56
7
3
9080-2
9080-5
9080-4
9080-1
Reference Only
