Manitowoc Grove RT530E-2 Service And Maintenance Manual

HYDRAULIC SYSTEM RT530E-2 SERVICE MANUAL
2-72 Published 4-22-15, Control # 556-00
8. Install the replacement piston seal and wear rings on the outside of the piston.
9
1
3
4
2
13
7
5
6
8
10
12
FIGURE 2-39
14
8
6815
2
11
Item Description
1 Barrel
2Rod
3Piston
4 Head
5Spacer
6Nut
7 Piston Seal
Item Description
8 Wear Ring
9O-ring
10 O-ring
11 Backup Ring
12 Seal
13 Wiper
14 Wear Ring
Reference Only
