ELECTRIC SYSTEM RT530E-2 SERVICE MANUAL
3-14 Published 4-22-15, Control # 556-00
4. Install nylon flat washer, leather washer, spacer, and nut
on motor shaft. Tighten nut.
5. Install wiper arm and blade on motor shaft.
6. Connect the electrical leads to the wiper motor as
marked before removal.
7. Turn the battery disconnect switch to the ON position.
Check
1. Operate the skylight wiper. Verify it works. (Replace
wiper blade as needed if it streaks or otherwise wipes
poorly.)
