RT530E-2 SERVICE MANUAL ELECTRIC SYSTEM
GROVE
3
Table 3-6Amp Extraction Tool Table
Table 3-7
Amp Crimping Tool Table
Table 3-8
Deutsch Extraction Tool Table
Table 3-9
Deutsch Crimping Tool Table
Description Amp Part Number Grove Part Number
14 gauge wire (connectors) 305183 9999100176
12 to 8 gauge wire (connectors) 91019-3 9999100175
4 to 9 circuit (in-line connectors) 453300-1 N/A
15 circuit (in-line connectors) 458944-1 N/A
Description Amp Part Number Grove Part Number
Tool Die Tool Die
14 to 12 gauge wire 69710-1 90145-1 9999100177 N/A
10 to 8 gauge wire 69710-1 90140-1 9999100177 9999100178
4 to 9 circuit
(in-line connectors
69710-1 90306-1 9999100177 N/A
15 circuit
(in-line connectors
90299-1 -- N/A --
Description Deutsch Part Number Grove Part Number
12 gauge wire 114010 9999100194
16 gauge wire 0411-204-1605 9999100195
8-10 gauge wire 114008 7902000012
4-6 gauge wire 114009 7902000009
Description Deutsch Part Number Grove Part Number
12, 14, 16, 18, 20 gauge wire HDT48-00 9999100808
4, 6, 8, 10 gauge wire HDT 04-08 9999100842
Reference Only
