RT530E-2 SERVICE MANUAL BOOM
GROVE
4
41
43
44
45
29
40
38
37
30
31
39
23
28
32
30
37
38
31
5
22
30
31
32
10
1
2
3
10
4
34
36
35
33
21
34
36
35
34
36
35
8476-1
FIGURE 4-1 continued
Item Description
28 Telescope Cylinder Inner Rod
29 Telescope Cylinder Outer Rod
30 Lower Rear Side Wear Pads
31 Bottom Wear Pads
32 Pins
33 Fly Extend Cables Keeper Plate
34 Adjustable Wear Pads
35 Keeper Plates
36 Offset Washers
Item Description
37
Retract Cable Sheaves, Shaft, Thrust Washers
and Spacers
38 Cable Retainer Bushings and Bolts
39 Fly Extend Cable Sled
40 Fly Extend Cable Sled Adjusting Bolt
41 Holding valve Port Block
42 Keeper Bolts
43 Pivot Shaft
44 Pin
45 Cotter Pin
Reference Only
