Manitowoc Grove RT530E-2 Service And Maintenance Manual

Published 4-22-15, Control # 556-00 1-5
RT530E-2 SERVICE MANUAL INTRODUCTION
1
GROVE
Remove: Auxiliary Hoist Cable (453 ft) of 5/8
35 x 7
-121.92 (-48.00) -179 (-394) 59 (131) -238 (-525)
Remove: Main Hoist Cable (450 ft) of 5/8 6 X
37
-60.96 (-24.00) -174 (-383) 29 (64) -203 (-447)
Add: Aux Hoist (Replace IPO Cwt With Aux
Hoist and Cable)
-109.22 (-43.00) 174 (383) -52 (-114) 225 (497)
Sub: Optional Cable on Main Hoist (453 ft of
5/8 inch 35 X 7)
-60.96 (-24.00) 5 (11) -1 (-2) 6 (13)
Sub: Tier 3 Engine -157.48 (-62.00) -17 (-37) 7 (16) -24 (-53)
Sub: 16.00 X 25 Titan Tires 182.9 (72.00) -63 (-140) -32 (-70) -32 (-70)
Sub: Kessler Axles 175.26 (69.00) -86 (-190) -41 (-91) -45 (-99)
Description
CG From Rear
Axle cm (in)
Weight
kg (lb)
Front Axle
kg (lb)
Rear Axle
kg (lb)
Reference Only

Manitowoc Grove RT530E-2 Specifications

General

Brand	Manitowoc
Model	Grove RT530E-2
Category	Construction Equipment
Language	English
