Manitowoc Grove RT530E-2 Service And Maintenance Manual

INTRODUCTION RT530E-2 SERVICE MANUAL
1-4 Published 4-22-15, Control # 556-00
Table 1-1
Axle Weight Distribution Table
Description
CG From Rear
Axle cm (in)
Weight
kg (lb)
Front Axle
kg (lb)
Rear Axle
kg (lb)
Basic Unit
Maximum Axle Loads Allowed 16783 (37000) 16783 (37000)
Maximum Axle Loads Allowed while Towing 14969 (33000) 14969 (33000)
Maximum Tire Loads Allowed 15604 (34400) 15604 (34400)
Standard Carrier Assy. 4 x 4; Plus all Fluids 158.83 (62.53) 12451 (27449) 5406 (11919) 7044 (15530)
Superstructure w/Cab Plus w/Main Hoist 68.66 (27.03) 3862 (8514) 725 (1598) 3137 (6916)
Pinned on Counterweight -119.63 (-47.10) 3817 (8416) -1249 (-2753) 5066 (11169)
Boom Assembly; w/(2/3) Sheaves, RCL,
Pivot Pins
427.43 (168.28) 5081 (11202) 5938 (13091) -857 (-1889)
Lift Cylinder & Lower Shaft 218.29 (85.94) 587 (1293) 350 (772) 236 (521)
Complete Basic Machine
4 x 4 chassis; Cummins QSB 6.7 Tier
4engine w/ transmission; front and rear
axles; 20.5 x 25 tires; main hoist
w/137 m (450 ft) of 5/8 in. 6 X 37 cable; full
fuel and hydraulic oil
158.37 (62.35) 25798 (56874) 11171 (24627) 14627 (32247)
Add To Basic Unit Weight
7.9 to 13.7 m (26 to 45 ft)Tele Boom
Extension
565.15 (222.50) 794 (1750) 1227 (2704) -433 (-954)
Boom Ext. Carrier Brackets (Bolt On) 441.96 (174.00) 116 (256) 140 (309) -24 (-53)
Auxiliary Boom Nose - Installed 916.94 (361.00) 48 (105) 119 (263) -72 (-158)
30 metric ton (33 ton), CE Hookblock (3
sheave) Stowed in Tray
396.24 (156) 292 (644) 317 (698) -24 (-54)
27.3 metric ton (30 ton), Hookblock Stowed
in Tray
396.24 (156.00) 263 (580) 285 (628) -22 (-48)
13.5 metric ton (15 ton), Hookblock Stowed
in Tray
396.24 (156.00) 193 (425) 209 (460) -16 (-35)
7 metric ton (7.5 Ton), Headache Ball
(Swivel) - Attached to Front O/R Box
581.66 (229.00) 167 (369) 266 (587) -99 (-218)
Storage Tray Mats 337.82 (133.00) 20 (43) 18 (40) 1 (3)
Rear Mounted Pintle Hook -162.56 (-64.00) 5 (11) -2 (-5) 7 (16)
Driver Controlled Differential Locks 177.80 (70.00) 19 (41) 9 (20) 10 (21)
Russian Certification Package 127.00 (50.00) 28 (61) 10 (21) 18 (40)
Air Conditioning - Carrier and superstructure
components
38.10 (15.00) 44 (98) 5 (10) 40 (88)
360 Degree Swing Lock 205.74 (81.00) 29 (64) 16 (36) 13 (28)
Driver 187.96 (74.00) 113 (250) 58 (128) 55 (122)
CE Components - w/Main Hoist 10.16 (4.00) 285 (628) 8 (17) 277 (611)
CE Components - w/Main & w/Aux Hoists 15.24 (6.00) 274 (603) 11 (25) 262 (578)
Reference Only
