Manitowoc Grove RT530E-2 Service And Maintenance Manual

Published 4-22-15, Control # 556-00 4-31
RT530E-2 SERVICE MANUAL BOOM
GROVE
4
6033
7
8
9
10
11
6
12
13
14
5
4
3
2
1
15
FIGURE 4-37
Item Description
1 Boom Base Section
2 Inner Mid Section
3 Outer Mid Section
4 Fly Section
5 Upper Sheave Cable Retainer
6 Left SIde Attachment Pins
7 Boom Nose Dead End Lug
8 Lower Sheave Cable Retainer
Item Description
9 Alignment Jack
10 Offset Pin
11 Mast Assembly Stowage Pin
12 Mast Assembly
13 Mast Assembly Cable Retainer
14 Right Side Attachment Pins
15 Jack handle
Reference Only
