Manitowoc Grove RT530E-2 Service And Maintenance Manual

BOOM RT530E-2 SERVICE MANUAL
4-30 Published 4-22-15, Control # 556-00
5
6
7
8
2
1
3
DETAIL B
DETAIL A
4
6032
9
FIGURE 4-36
12
11
Item Description
1
Swingaway Pin on Nose Assembly or
Telescoping Section
2 Swingaway Base
3 Main Boom base Section
4 Upper Boom nose Sheaves
5 Lower Boom Nose Sheaves
Item Description
6 Right Side Attachment Pins
7 Left Side Attachment Pins
8 Mast Assembly
9 Telescoping Section Pin (Optional)
10 Rear Stowage Bracket
11 Front Stowage Bracket
Reference Only
