RT530E-2 SERVICE MANUAL HOIST AND COUNTERWEIGHT
GROVE
5
Item Description
1 Counterweight
2Pin Assembly
3 Capscrew
4Hex Nut
5Jam Nut
6Grill
7 Retaining Nut
8Flat Washer
9 Lock Washer
10 Capscrew
11 Lock Pin
6830
FIGURE 5-7
3, 4, 5
7, 8, 9, 10
6
1
2, 11
3, 4, 5
2, 11
Reference Only
